CNC Spring Making Machine RNJ-8545




Description

Description for CNC Spring Making Machine RNJ-8545

The Multiple axis CNC spring machine can be produced (0.2-20.0mm wire diameter).
The crimping function has a detachable installation function, which has a faster processing speed for corner processing and arc bending. wire transfer system solves the fact that the entire wire feed of the spring machine can be rotated 360 degrees in the forward and reverse directions during the wire feed process. Achieve Multiple angle forming and cutting, etc., in order to facilitate the completion of the various types of spring samples and production you require.

Technical Parameter：

CNC Spring Making Machine – RNJ-8545
Wire diameter of coiled material1.5-4.5mm
Max outer diameter of coiled springMax Φ110mm
Wire feed instruction value±0.01+9999.99
Cam instruction value±0.1°-±359.9°
Max Wire Feed Speed0~80m/min
Cam rotation speed1~60RPM
Max Wire Feed lengthInfinite length
Number of axis axis
Wire feed servo power5.5KW
Cam servo motor5.5KW
Input voltage380V
Program data storageOver 2000 pcs.
Size1800×1700×2100mm
Weight2800 kg

Advantages & operation processes CNC Spring Making Machine RNJ-8545

Advanced servo-controlled spring manufacturing solution with automated workflow and custom configuration options

Device Function
  1. Automatically connect the spring manipulator to catch the spring when retracting and move to the next station.
  2. The winding process is fully automatic.
  3. The reducer uses servo-specific reducer, which has large torque, high transmission efficiency, no oiling and no maintenance for life.
Mainly used inRailway, engineering machinery and other fields
Our advantages
  1. Use servo control system with very high quality components.
  2. Custom-made is available to meet your detailed requirement.
  3. We are able to provide whole production line, including molds and technical support.
